RGB LED Neon Round Waterproof Horizontal Bend Side Emitting - ETL 24VDC - 197"(5m)

Round RGB Neon RGB Neon Neon Colors Neon Dimension Neon Wires
Round RGB Neon RGB Neon Neon Colors Neon Dimension Neon Wires

SKU: LN-DX-NE-RGB-RH-5

$174.99
Order will ship: Monday, Jul 01 * If placed by Monday, Jul 01, 2:00pm PST.
Free Shipping On orders over $250 within the Continental U.S. * Excluding oversized items. See Exclusions
Buy
Discount
You Pay
6+
5% off
$166.25
13+
8% off
$161.00
31+
12% off
$154.00
61+
15% off
$148.75
100+
18% off
$143.50

Description

Our newly added Side Emitting RGB Neon Flex has a special rounded top design that mimics traditional neon lighting without dangerous operating voltage or harmful chemicals. Each 16.4ft of neon flex is designed with a dual core milky silicone extrusion that is salt water resistant and won't yellow in the sun over time. The spherical design outputs 170° beam angle, side emitting which allows for bending on a horizontal axis. There is no need for a plastic cover or diffuser when using this product, create vibrant colors and color change functions without any visible dots or hot spots. This product is ideal for architectural accents, signs, displays, night clubs, storefronts, interior designs, or any application where a dot free color changing light is desired. Six 5050 LEDs per every 3.94" cuttable section produces 35 lumens per foot when all colors are on full brightness. Each 5 meter roll comes with 10 mounting clips, 10 self-tapping screws, 1 wire lead setup, and one end cap. You can cut this neon flex every 3.94" but you must be able to solder a wire lead to re-connect. A power draw of 3.51 watts of 24VDC power for each foot means the 16.4ft roll would need 58 watts minimum of 24VDC power and RGB color control to light on full brightness. This product is ETL listed, RoHS and CE approved.

Specifications

SPECIFICATIONS
ModelWaterproof RGB Neon FLex, Round, Side Emitting - ETL 24VDC - 197" (5m)
SKULN-DX-NE-RGB-RH-5
Dimensions197" x 0.47" x 0.79"H
Connection Type4 Wire RGB(+)
LED Chip Type5050
LED Quantity6 SMDs per 3.94 inches
LEDs Per Strip300 RGB 3 in 1 SMD LEDs
Input Power24VDC Constant Voltage
Watts3.51W per foot
Beam Angle170°
Lumens35 lm/ft
RatingIP67 Waterproof
Ambient Temperature-4°~113°F
Max Serial Connection20 Feet
CertificationETL Listed, RoHS, CE
Product Lifetime50,000 Hours
Warranty Period2 Years

Dimensions

Neon Side View
