40" Brightstar OSRAM RGBW LED Wall Washer - ETL Listed - 54W, 24VDC

Osram RGBW Wall Washer Mounting Dimensions RGB+4000K LED Wall Washer Red Wash Green Wash Blue Wash
Osram RGBW Wall Washer Mounting Dimensions RGB+4000K LED Wall Washer Red Wash Green Wash Blue Wash

SKU: WW-WN-RGBW-54W-24V

$279.99
Order will ship: Tuesday, Mar 25 * If placed by 2:00pm PST.
Free Shipping On orders over $250 within the Continental U.S. * Excluding oversized items. See Exclusions
Buy
Discount
You Pay
6+
5% off
$266.00
11+
8% off
$257.60
21+
12% off
$246.40

Description

Attract attention, stand out and provide a memorable experience for your customers and guests using our high quality ETL Listed IP66 4 in 1 Wall Washers in both indoor and outdoor spaces. Our 39.37" long x 2.52" wide 4in1 24VDC RGBW LED Wall Washers have 24 Osram LEDs on board to provide ample color changing + 4000K static white output that can create a range of over 4 billion color variations using 255 level grey scale control. Using Red, Green, Blue and a Neutral White color output you can achieve a wide array of color settings as well as static white output that can shine up to 100 feet. Consuming 54 watts of 24 volt DC power each fixture requires at least 2.25 amps of 24V current to operate at full brightness. Our RGBW wall washers can be controlled with a standard remote controlled or smart phone 24VDC rated 4 channel color controller, or use with a 4 channel DMX decoder to control using a DMX lighting controller. Each fixture has a 50,000 hour lifetime span and is ETL Listed, CE and RoHS approved.

Specifications

SKU Color Kelvin Lumens Voltage Watts Rating Beam Operating° Max Serial Lifespan Warranty
WW-WN-RGBW-54W-24V RGBW 4,000K 1,890lm 24VDC 54W IP66 60° -4°~131°F 3 Fixtures 100K Hours 2 Years
24VDC RGBW Wall Washer Specification Sheet

Dimensions

Length Width Height Wire Length Wire Gauge Mounting Holes Shipping Weight
39.37"(1000mm) 2.52"(64mm) 5.12"(130mm) 19.69"(50cm) 18AWG 0.98" * 0.79" (.24"⌀)(25*20mm 6mm⌀) 6.9lbs
RGBW Wall Washer Dimensions

Wiring

RGBW Wall Washer Wiring
