SKU: LN-SC-NEOT-WW-5
Description
Each 5 meter roll of well-built mini neon LED strip light has a rugged IP67 waterproof rated UV resistant PVC housing to create vibrant dot free illumination for a line of light effect. The milky coating and design of this special strip light delivers 100% light diffusion with no hot spots, similar to the look of a neon tube. This strip is designed to bend on a vertical axis and can be used to wrap perimeters, down light, up light or any application requiring the strip to be bent how it is rolled up on the reel. Use our mini neon led indoors and outdoors for a variety of lighting projects both functional and decorative. This strip requires 24 volt DC input and consumes 3.81 watts of power per foot, at full brightness. This product is dimmable by our PWM low voltage dimmers or by our magnitude dimmable power supplies with compatible wall switch. This strip can be cut and re-connected every 1.5" and comes with 1 extra wire lead setup, 1 end cap, and 20 plastic mounting clips.
Specifications
SPECIFICATIONS | |
Model | Mini Neon Top Emitting, Waterproof Warm White |
SKU | LN-SC-NEOT-WW-5 |
Dimensions | 197" x 0.52" x 0.40"H |
Connection Type | 2 Wire (+/-) |
LED Chip Type | 3014 |
LED Quantity | 7 SMDs per 1.5 inches |
LEDs Per Strip | 910 SMD LEDs |
Input Power | 24VDC Constant Voltage |
Watts | 3.81W per foot |
Beam Angle | 120° |
Lumens | 160.67 lm/ft |
CRI | >80 |
Kelvin | 3000-3500K |
Rating | IP67 Waterproof |
Operating Temp | -4°~104°F |
Max Serial Connection | 16.4 Feet (5m) |
Certification | ETL, RoHS, CE |
Warranty Period | 2 Years |
Downloads
Dimensions
![Neon Top View](https://cdn.commercev3.net/cdn.ecolocityled.com/images/neon-t-dimension.gif)
