OPAC-30 Extrusion with Wings - 1" Wide x 0.2" Deep
SKU: EX-KL3-6
$22.75 per meter*aluminum channel price (no cover)
Order will ship: Thursday, Nov 21
* If placed by 2:00pm PST.
Free Shipping On orders over $250 within the Continental U.S.
* Excluding oversized items. See Exclusions
Description
The OPAC-30 extrusion from KLUS is intended to be used to build slim flush mount LED lighting fixtures in drywall, wood, stone or any other rigid material with at least 9mm of thickness. Using the specialized mounting springs the OPAC-30 profile can be mounted securely and has a variety of flat and shaped cover options to create custom recessed lighting fixtures in small spaces. The extrusion can fit two 10mm-wide LED strips or one LED strip with a width of more than 10 mm but not greater than 21 mm.
Specifications
| SPECIFICATIONS | |
| Model | OPAC-30 Aluminum Extrusion |
| SKU | EX-KL3-6 |
| Dimensions | 39.37"L x 2.05"W x 0.37"H |
| Base Width | 0.94" |
| Material | Aluminum |
| Cover | Polycarbonate |
| Mounting | Screws, Mounting Springs |
| Available Lengths | 1M, 2M |
| Available Finishes | Anodized |
Downloads
| Click For Product Data Sheet |
| Click For General Instructions |
| Click for Cover Instruction |
Reviews
|
Product Rating |
Write a Review |
|---|---|
|
|
|
|
- There are currently no reviews for this product
|
|
Questions
