2 Output x 96W Magnetron Class 2 Dimmable LED Driver with Junction Box - 24VDC
SKU: PS-EN-192-24
$229.99
Order will ship: Monday, Mar 24
* If placed by 2:00pm PST.
Free Shipping On orders over $250 within the Continental U.S.
* Excluding oversized items. See Exclusions
Buy
Discount
You Pay
5+
5% off
$218.50
10+
10% off
$207.00
Description
The Magnetron UL listed Dimmable LED driver presents a compact design within a durable metal casing with various knockouts for secure and permanent 24VDC dimmable power. Boasting Multi-Channel UL Listed Class 2 specifications, it supports dimming down to 1% across an array of compatible wall switches types: Incandescent/CLF/LED/MLV/ELV. With an 87% efficiency at full load and built-in protection features, it's ideal for 24VDC LED Strip Light applications in dry, damp and wet locations.
Specifications
| SKU | Dimensions | DC Output | Max Load | Max Current | Rating | AC Input | Power Factor | Efficiency |
|---|---|---|---|---|---|---|---|---|
| PS-EN-192-24 | 3.96" x 1.61" x 7.67" | 24VDC | 96W x 2 | 4A x 2 | IP65 | 120VAC | 0.92 | 87% |
