RGB Controller with Audio control RF Remote, 12-24VDC 4Ax3CH
SKU: LC-OL-8RGBC-WR
Description
This cool RGB LED Controller can control your RGB LED lights by music or sound. The LED lights will change with sound. It also comes with a 4 button RF Remote. It can be used to control RGB LED Ribbon, RGB LED Modules or RGB LED Lights. This controller is for use with 4 pin, 3 loop, common anode style RGB LED Lighting. You need a 12VDC or 24VDC Constant Voltage Power Supply for this controller. The power supply can be connected either with 5.5mm x 2.1mm female plug or by screw down wire connections. 4A per channel or 144W Max at 12VDC or 288W Max at 24VDC. RGB connection wires are screw down style. MODES: Brightness adjustment, 7 static colors, 3 color (RGB) jumpy change (instant change to next color), 7 color jumpy change, 3 color fading change (RGB), 7 color fading change, 3 color change by audio control & 7 color change by audio control. Remote control requires (1) 12V/23A type battery, one is included. Unit has a built in mic and a jack connection for 3.5mm earphone audio input. Each LED Light Dimmer is paired for use with a unique remote so as to prevent command crossover when using multiple LED Light Dimmer units.
Specifications
Model | RGB LED by Audio Controller W/Remote |
SKU | LC-OL-8RGBC-WR |
Dimensions | 5.125" X 2.5" X 1"T |
Input Connection | 2 Wire (+/-) |
Output Connection | 4 Wire RGB(+) |
Input Power | 12VDC |
Output Power | 4A x 3CH |
Maximum Watts | 12VDC - 144W 24VDC - 288W |
Rating | Indoor |
Operating Temp | 0° ~ 125°F |
Warranty Period | 1 Year |
Previous Mode on Power Cycle | Yes |
RF Remote Radius | 50ft (line of sight) |
Static Color Choices | 7 Static Modes 100 Levels Dim |
Color Changing Modes | 6 Modes See Modes
|
